Gear Catalog KG2003
KG STOCK GEARS catalog was born as a first standard gear catalog in Japan for over half a century ago. Since the first gear catalog we have expanded our product range. As a result, currently about 4,000 standard gears are available through the catalog. The catalog contains gearboxes and almost all kinds of gears of spur gears, rack gears, worm gear pair, miter gears, bevel gears, screw gears, and internal gears in various materials. You can download both complete version and separate version of each gear types from the following.

カタログ
Download Complete Catalog in PDF ( 11.41MB)


RIGHT ANGLE
GEARBOXES
ANTI-BACKLASH
SPUR GEARS
SPUR GEARS
RIGHT ANGLE GEARBOXES ANTI-BACKLASH SPUR GEARS SPUR GEARS
Types of Gears
Bevel, Hypoid, Worm
Shaft diameter
φ3 – φ25
Ratio
1 : 1 – 50 : 1
Module
0.5 – 2.0
Material
Stainless steel, Aluminum,
Carbon steel,
Chromium molybdenum steel
Module
0.3 – 5.0
Material
Stainless steel, Brass, Plastic,
Carbon steel,
Chromium molybdenum steel
PDF CATALOG PDF CATALOG PDF CATALOG

RACK GEARS MITER GEARS BEVEL GEARS
RACK GEARS MITER GEARS BEVEL GEARS
Material
0.3 – 3.0
Material
Stainless steel, Brass, Plastic,
Carbon steel,
Chromium molybdenum steel
Module
0.5 – 3.0
Material
Stainless steel, Brass, Plastic,
Carbon steel,
Chromium molybdenum steel
Module
0.5 – 3.0
Material
Stainless steel, Brass, Plastic,
Carbon steel,
Chromium molybdenum steel
PDF CATALOG PDF CATALOG PDF CATALOG

WORM GEARS INTERNAL GEARS SCREW GEARS
WORM GEAR INTERNAL GEARS SCREW GEARS
Material
0.5 – 3.0
Material of worms
Stainless steel, Carbon steel
Material of worm wheels
Brass, Aluminum bronze,
Plastic, Grey iron casting
Module
0.5 – 1.0
Material
Brass, Carbon steel
Module
1.0 – 3.0
Material
Stainless steel, Plastic,
Carbon steel
PDF CATALOG PDF CATALOG PDF CATALOG
